Series SA3500

SA3500 Slim Sliding Door

Overview

About the SA3500 series

A marvellously designed slim series — the ideal solution for sliding doors that demand aesthetics, performance and functionality. Interlocking profiles add elegance, while high wind resistance makes it ideal for high-rise residential buildings.

Technical Characteristics

System Specification

SYSTEM TECHNICAL SPECIFICATION
Profile Alloy	6063 - T6
Glass Thickness (mm)	6, 8, 13.5, 22, 24
Max Height Shutter (mm)	2800
Multi Locking	Yes
Max Sq.mtr / Sash	4.5
Maximum Weight of each Shutter (Kgs)	200
Corner Opening	Possible
Mosquito Mesh	Not Possible

APPLICATION PROFILE DETAILS
Frame Height (mm)	39
Frame Width — 2T2S (mm)	92
Frame Width — 3T3S (mm)	142
Sightline at Interlock (mm)	20
Center Meeting — 2T4S (mm)	58

Gallery

Installations & Profile Detail
