Series SA3000
Considered by many to be the best in aesthetics, quality, durability and performance — and probably the only true slim-line series in this segment. Single-point and multipoint flush locking, with the option to merge with our fixed glass railing system, saving space and cost.
Technical Characteristics
| SYSTEM TECHNICAL SPECIFICATION | |
|---|---|
| Profile Alloy | 6063 - T6 |
| Glass Thickness (mm) | 6, 8, 11.5, 22, 24 |
| Max Height Shutter (mm) | 2400 |
| Multi Locking | Yes |
| Max Sq.mtr / Sash | 3.6 |
| Maximum Weight of each Shutter (Kgs) | 150 |
| Corner Opening | Possible |
| Mosquito Mesh | Not Possible |
| APPLICATION PROFILE DETAILS | |
|---|---|
| Frame Height (mm) | 39 |
| Frame Width — 2T2S (mm) | 83 |
| Frame Width — 3T3S (mm) | 128 |
| Sightline at Interlock (mm) | 20 |
| Center Meeting — 2T4S (mm) | 60 |
